Opti Notched Auto Belt

Stock Code:
13AX0950_OPTI
$35.55 incl GST

Stock Locations

  • Ballarat:
    4 In Stock
  • Shepparton:
    Special Order
Make an Enquiry
Add to Favourites

Description

DESCRIPTION

Optibelt MARATHON X

Optibelt Notched Auto Belt

V-belt for passenger cars - open-flanked, form-toothed

The optibelt MARATHON X was developed for driving auxiliary units in passenger car and light commercial vehicle engines.

13AX0950_OPTI

13A950 or 13A0950

Specifications

• 13A Section
• 950.00 mm Reference Length
• Cogged
• Single Belt

For use in cars and light commercial vehicles

The optibelt MARATHON X was developed for driving ancillary components in the engines of cars and light commercial vehicles. This raw edged V-belt with moulded cogs is distinguished by its high level of durability and its low-stretch tension behaviour.

Technical information: Further development of MARATHON 1

The optibelt MARATHON X V-belt is a further development of the optibelt MARATHON 1. Both products cover the same vehicles and original part numbers and comply with the relevant original equipment standards. Individual dimensions are being continuously converted to the new design, as of June 2018. More detailed information can be provided on request.

Product Benefits

  • High level of durability
  • High efficiency
  • Low-maintenance operation
  • Very smooth running
  • Excellent tension behaviour

Temperature guide

  • The belt is made of temperature resistant EPDM (-40 to +120 °C).

Safety tips

  • Please observe installation regulations and safety instructions supplied by the manufacturer of the car
  • Please only perform installation of the drive belts with special tools and a minimum exertion of force. The use of screwdrivers, crowbars or such tools is prohibited
  • Do not treat the control unit components with corrosive chemicals. Belts must not come into contact with oil or similar substances
  • Fill in the timing belt adhesive label legibly and attach it firmly in the engine compartment
  • If individual components are faulty, the other components must also be replaced

Storage

  • Store timing belts dry and at +15 to +25ºC.
  • Improper storage, e.g. exposure to oxygen, light, extreme temperatures or moisture, can change the physical properties and render the V-belt unusable
  • Until the V-belts are used, they should be stored in their original packaging and free of tension
  • Do not exceed a height of 300 mm when stacking the belts, otherwise deformation may occur.

Compatible with these vehicles:

Alfa Romeo

145

  • Belt A/C 1994-1997, 1.7L, 4 cyl, 16V, DOHC, MPFI, 95kW, EngCode: AR33401, NZ
  • Belt A/C 1994-1997, 1.6L, 4 cyl, 8V, SOHC, MPFI, 76kW, EngCode: AR33201, Import

146

  • Belt A/C 12/1994-12/1996, 1.6L, 4 cyl, 8V, SOHC, MPFI, 76kW, EngCode: AR33201, NZ
  • Belt A/C 12/1994-12/1996, 1.7L, 4 cyl, 16V, MPFI, 95kW, EngCode: AR33401, NZ

33

  • Belt A/C 10/1987-09/1988, 1.7L, 4 cyl, 8V, SOHC, Twin Carb, 82kW, EngCode: AR30550
  • Belt A/C 10/1988-06/1990, 1.7L, 4 cyl, 8V, SOHC, EFI, 78kW, EngCode: AR30558
  • Belt A/C 07/1990-12/1992, 1.7L, 4 cyl, 16V, DOHC, EFI, 95kW, EngCode: AR30747
  • Belt A/C 05/1991-12/1992, 1.7L, 4 cyl, 16V, DOHC, EFI, 4WD, 95kW, EngCode: AR30747

GTV

  • Belt A/C 05/1983-02/1988, 2.5L, V6, DOHC, EFI, 117kW, EngCode: AR01646

Audi

100

  • Belt P/S (without A/C) 03/1985-12/1990, 2.2L, 5 cyl, 10V, SOHC, EFI, C3, 101kW, EngCode: KU, NZ
  • Belt P/S 04/1987-09/1991, 2.2L, 5 cyl, 10V, SOHC, EFI, C3, 101kW, EngCode: HX
  • Belt P/S 01/1988-03/1991, 2.3L, 5 cyl, 10V, SOHC, EFI, C3, 100kW, EngCode: NF
  • Belt P/S 01/1988-03/1991, 2.3L, 5 cyl, 10V, SOHC, EFI, C3, 98kW, EngCode: NG

200

  • Belt Hyd. P 1984-1988, 2.2L, 5 cyl, 10V, SOHC, TEFI, Turbo, 134kW, EngCode: KG, Import

Holden

Piazza

  • Belt A/C 04/1986-11/1987, 2.0L, 4 cyl, 8V, SOHC, TEFI, Turbo, 110kW, EngCode: 4ZC1T

Honda

Prelude

  • Belt A/C 01/1983-12/1985, 1.8L, 4 cyl, 8V, SOHC, 2 carb, EngCode: ET

Iveco

Eurocargo

  • Belt A/C 1997-04/2001, 5.9L, 6 cyl, 12V, OHV, Diesel Inj., Turbo, Diesel, ML100, 100E18, EngCode: 8060.45
  • Belt A/C 11/1998-03/2002, 3.9L, 4 cyl, 8V, OHV, Diesel Inj., Turbo, Diesel, ML75, EngCode: 3.9
  • Belt A/C 1999-2002, 5.9L, 6 cyl, 12V, OHV, Turbo, Diesel, ML120, EngCode: 8060.45

Mazda

929

  • Belt P/S 06/1987-08/1991, 3.0L, V6, 18V, SOHC, MPFI, HC, EngCode: JE
  • Belt P/S 01/1990-08/1991, 3.0L, V6, 24V, DOHC, MPFI, HC, EngCode: JE

B2200

  • Belt A/C 03/1988-02/1993, 2.2L, 4 cyl, 8V, SOHC, Carb, EngCode: F2

B2600

  • Belt P/S 02/1999-11/2006, 2.6L, 4 cyl, 12V, SOHC, MPFI, EngCode: G6

E2000

  • Belt A/C 01/1987-11/1996, 2.0L, 4 cyl, 8V, SOHC, Carb, EngCode: FE
  • Belt A/C 12/1996-12/1998, 2.0L, 4 cyl, 8V, SOHC, Carb, EngCode: FE

Mercedes Benz

420SE

  • Belt A/C 04/1986-03/1992, 4.2L, V8, 16V, SOHC, EFI, W126, EngCode: M116.965

560SE

  • Belt A/C 04/1986-03/1992, 5.6L, V8, 12V, SOHC, EFI, C126, EngCode: M117.968
  • Belt A/C 04/1986-03/1992, 5.6L, V8, 12V, SOHC, EFI, W126, EngCode: M117.968

560SL

  • Belt A/C 04/1986-03/1992, 5.6L, V8, 12V, SOHC, EFI, R107, EngCode: M117.968

Mitsubishi

Cordia

  • Belt Alt (With P/S) 04/1983-10/1984, 1.6L, 4 cyl, 8V, SOHC, Carb, EngCode: 4G32

Express (1986-Current)

  • Belt A/C 09/1990-08/1991, 2.5L, 4 cyl, SOHC, Diesel, SG, EngCode: 4D56

L200 Express Utility

  • Belt A/C 1997-2006, 2.8L, 4 cyl, 8v, SOHC, Direct Inj., EngCode: 4M40

Magna

  • Belt A/C 06/1989-04/1992, 2.6L, 4 cyl, 8V, SOHC, Carb, TP, EngCode: 4G54
  • Belt A/C 06/1989-04/1992, 2.6L, 4 cyl, 8V, SOHC, MPFI, TP, EngCode: 4G54
  • Belt A/C 04/1991-03/1994, 2.6L, 4 cyl, 8V, SOHC, Carb, TR, EngCode: 4G54
  • Belt A/C 04/1991-03/1994, 2.6L, 4 cyl, 8V, SOHC, EFI, TR, EngCode: 4G54
  • Belt A/C 04/1991-03/1994, 2.6L, 4 cyl, 8V, SOHC, MPFI, TR, EngCode: 4G54
  • Belt A/C 03/1994-02/1997, 2.6L, 4 cyl, 8V, SOHC, MPFI, TS, EngCode: 4G54
  • Belt A/C 03/1994-03/1997, 2.6L, 4 cyl, 8V, SOHC, Carb, TS, EngCode: 4G54

Pajero

  • Belt A/C 07/1993-05/2000, 2.8L, 4 cyl, 8V, SOHC, Diesel Inj, I/C Turbo, Diesel, NJ, 92kW, EngCode: 4M40T
  • Belt A/C 11/1993-06/2000, 2.8L, 4 cyl, 8V, SOHC, Diesel Inj, Turbo, Diesel, NJ, NK, NL, 92kW, EngCode: 4M40T
  • Belt A/C 07/1993-05/1997, 2.8L, 4 cyl, 8V, SOHC, Diesel Inj, Diesel, NJ, 71kW, EngCode: 4M40
  • Belt A/C 11/1993-05/1997, 2.8L, 4 cyl, 8V, SOHC, Diesel Inj, Diesel, NK, 71kW, EngCode: 4M40
  • Belt A/C 09/1995-06/2000, 2.8L, 4 cyl, 8V, SOHC, Diesel Inj, I/C Turbo, Diesel, NJ, NK, NL, EngCode: 4M40T
  • Belt A/C 08/1997-06/2000, 2.8L, 4 cyl, 8V, SOHC, Diesel Inj, Turbo, Diesel, NL, EngCode: 4M40T
  • Belt A/C 05/2000-07/2002, 2.8L, 4 cyl, 8V, SOHC, Diesel Inj, I/C Turbo, Diesel, NM, 92kW, EngCode: 4M40T

Triton

  • Belt A/C 10/1996-06/2006, 2.8L, 4 cyl, 8V, SOHC, Direct Inj, Diesel, MK, 71kW, EngCode: 4M40
  • Belt A/C 02/2003-08/2006, 2.8L, 4 cyl, 8V, SOHC, Direct Inj, Turbo, Diesel, MK, 92kW, EngCode: 4M40T

Nissan

720

  • Belt Alt 1980-09/1984, 2.2L, 4 cyl, 8V, OHV, DFI, Diesel, EngCode: SD22

Homy

  • Belt Alt 1982-1986, 2.3L, 4 cyl, 8V, OHV, DFI, Diesel, E23, EngCode: SD23, Japan Import NZ

Patrol

  • Belt Alt (without A/C) 06/1980-1987, 3.3L, 6 cyl, 12V, OHV, Diesel, MQ, EngCode: SD33
  • Belt Alt (without A/C) 06/1980-1987, 3.3L, 6 cyl, 12V, OHV, Turbo, Diesel, EngCode: SD33T
  • Belt A/C (Or) 05/1999-09/2007, 4.2L, 6 cyl, 12V, OHV, Diesel Inj., Turbo, Diesel, GU, 114kW, EngCode: TD42T

Safari

  • Belt Alt W/O A/C 06/1980-10/1987, 3.2L, 6 cyl, 12V, OHV, Diesel, 160, EngCode: SD33
  • Belt Alt W/O A/C 08/1983-10/1987, 3.2L, 6 cyl, 12V, OHV, Diesel, 161, EngCode: SD33
  • Belt Alt W/O A/C 08/1983-10/1987, 3.2L, 6 cyl, 12V, OHV, Diesel, 161, EngCode: SD33T

Urvan

  • Belt Alt 09/1982-1986, 2.3L, 4 cyl, 8V, OHV, Diesel, EngCode: SD23

Porsche

928

  • Belt Air P 01/1986-12/1986, 5.0L, V8, 32V, DOHC, MPFI, S, EngCode: 81J
  • Belt Air P 01/1986-08/1991, 5.0L, V8, 32V, DOHC, MPFI, GT, EngCode: 81J
  • Belt Air P 01/1987-08/1991, 5.0L, V8, 32V, DOHC, MPFI, S4, EngCode: 81J
  • Belt Air P 04/1992-08/1995, 5.4L, 32V, DOHC, MPFI, GTS, EngCode: 81J

Subaru

Brumby

  • Belt Alt & W/P & A/C 1984-1985, 1.8L, 4 cyl, 8V, OHV, Carb, EngCode: EA81, 4WD
  • Belt Alt & W/P & A/C 1986-1988, 1.8L, 4 cyl, 8V, OHV, Carb, EngCode: EA81, 4WD
  • DL
  • Belt A/C & Idler 12/1984-12/1995, 1.8L, 4 cyl, 8V, SOHC, Carb, EngCode: EA82
  • GL
  • Belt A/C & Idler 12/1984-01/1995, 1.8L, 4 cyl, 8V, SOHC, Carb, EngCode: EA82, 4WD
  • Belt A/C & Idler 09/1988-06/1990, 1.8L, 4 cyl, 8V, SOHC, EFI, EngCode: EA82, 4WD

Toyota

Corolla

  • Belt A/C (Or) 11/1978-09/1981, 1.3L, 4 cyl, 8V, OHV, Carb, KE38, EngCode: 4K-C
  • Belt A/C (Or) 11/1978-09/1981, 1.3L, 4 cyl, 8V, OHV, Carb, KE55, EngCode: 4K-C
  • Belt A/C (Or) 10/1981-04/1985, 1.3L, 4 cyl, 8V, OHV, Carb, KE70, EngCode: 4K-C

Hiace

  • Belt A/C 01/1982-02/1984, 1.8L, 4 cyl, 8V, OHV, Carb, YH50, EngCode: 2YC

Volkswagen

Golf

  • Belt A/C 1982-1988, 1.8L, 4 cyl, 8V, SOHC, EFI, Type 2, 82kW, EngCode: DX, NZ
  • Belt A/C 1984-1987, 1.8L, 4 cyl, 8V, SOHC, MPI, Type 2, 82kW, EngCode: EV
  • Belt A/C 1984-1987, 1.8L, 4 cyl, 8V, SOHC, MPFI, Type 2, 82kW, EngCode: GX
  • Belt A/C 1986-1997, 1.8L, 4 cyl, 8V, SOHC, EFI, Type 2, 66kW, EngCode: GU, NZ
  • Belt A/C 1987-1989, 1.8L, 4 cyl, 8V, SOHC, MPFI, Type 2, 77kW, EngCode: RV
  • Belt A/C 1987-1991, 1.8L, 4 cyl, 8V, SOHC, EFI, Type 2, 82kW, EngCode: PB
  • Belt A/C 09/1990-07/1994, 1.8L, 4 cyl, 8V, SOHC, EFI, Type 2, 62kW, EngCode: RV

Passat

  • Belt A/C 1990-1993, 2.0L, 4 cyl, 16V, DOHC, EFI, 100kW, EngCode: 9A

Volvo

740

  • Belt P/S 01/1988-12/1991, 2.3L, 4 cyl, 8V, SOHC, EFI, EngCode: B230

940

  • Belt A/C (automatic) 11/1990-12/1992, 2.3L, 4 cyl, 8V, SOHC, TMPFI, Turbo, EngCode: B230FT
  • Belt A/C 01/1993-10/1995, 2.3L, 4 cyl, 8V, SOHC, MPFI, EngCode: B230F
  • Belt A/C 02/1993-10/1995, 2.3L, 4 cyl, 16V, DOHC, MPFI, EngCode: B230F

Please Note - The size of the belt should always be checked with original before purchasing. This is because sometimes different belts are used within the same model/engine variation when there is more than one type of alternator / air compressor / power steering pump / etc. used.

Downloads below

Click here for optibelt automotive catalogue

Still can't find what you're looking for? Our website is continuously being updated, so contact us by phone or email for anything else:

Phone:
03 5336 1111

Email:
online@iw.net.au

Details

  • Width:
    13 mm
  • Brand:
    OPTI
  • Number of Rows:
    1 Row
  • Belt Type:
    Notched - Raw Edge
  • Length:
    950 mm
