Conversion Chart

Serrated Flanged Bolt HT ZFS - M12x30 (Box=100)

HEC / CLASS 12.9 - M12
Stock Code:
BF12FCM120030
$4.70 incl GST

Stock Locations

  • Ballarat:
    Special Order
Make an Enquiry
Add to Favourites

Description

DESCRIPTION

Serrated Flanged Bolt D-Lok Zc Flake Silver M12X30

Hex Flange D-Lok Bolts are the highest strength hex head metric bolts. They are approx. 20% stronger than a class 10.9 and 40% than class 8.8. The bolts feature a flange under the head which removes the need for a separate washer and are serrated to lock and clamp the connection. It is fatigue resistant & re-usable with no reduction in performance

Applications: Equipment and machinery with constant vibration, forklifts, truck and large vehicles, mining equipment, motor bikes, conveyors and materials handling equipment, defence / military vehicles

Product
SERRATED FLANGED BOLT D-LOK

Finish
ZINC FLAKE SILVER >1000HRS

D-Lok bolts and nuts are coated with a Zinc Flake Coating which is hydrogen embrittlement risk free. Prior to this coating being available there has always been a risk that if the high tensile bolt wasn't plated correctly, and it can be hard to tell either way, failure could occur. Zinc Flake Coating bolts from Hobson resolve this. Test certicates and reports are available upon request. The coating is relatively new to the fastener industry, it has a similiar colour and appearance to mechancial galvanising and in sea salt testing results showed to last approximately 25 years in C4 environment or approximately 15 years in C5 environment

Note - NOT COMPATIBLE WITH GALVANIZED FASTENERS

Size
M12

Specification
HEC / CLASS 12.9

Bolts are made to class strength 12.9. They have a yield strength of 1220 and the tensile strength is 1220 Mpa compared to 8.8 yield strength of 640 and the tensile strength is 800Mpa

Length / Dimension
30

Thread
M12-1.75 x Fully Threaded Thread length on older stock may vary


Click here for bolt technical specifications

Click here for hobson high tensile product guide

Click here for hobson breaking strength guide

Click here for product finish comparisons

Click here for anti vibration paper

Click here for Zinc flake coating guide

Click here for hobson serrated flanged bolt & nut guide


Still can't find what you're looking for? Our website is continuously being updated, so contact us by phone or email for anything else:

Phone:
03 5336 1111

Email:
online@iw.net.au








Details

  • Left or Right Hand:
    Right Hand
  • Brand:
    Hobson
