High Stress HS Washer - PLN -M14x28.0x3.5 (Box=20)

Schnorr DIN 267 - M14
Stock Code:
WOHTLPM14
$12.67 incl GST

Stock Locations

  • Ballarat:
    Special Order
Make an Enquiry
Add to Favourites

Description

DESCRIPTION

High Stress HS Washer - Plain -M14x28.0x3.5 (Box=20)

(Price per unit)

Original Schnorr High stress load washers, HS

  • This safety washer is, in principle, a load washer with a smaller outer diameter than those according to DIN 6796.
  • A notable feature of these washers is the slight curved form, which provides a progressively increasing characteristic curve.
  • Despite the smaller outside diameter dimensions, this makes it possible to achieve the same load as the load washers according to DIN 6796.
  • These washers are primarily used when the space available is insufficient for standardised load washers.

Note

To ensure optimum strength, corrosion resistance, and long-term performance, washers should be selected from a material compatible with the bolt and nut. For example, use stainless steel washers with stainless steel fasteners, and Zinc plate washers with Zinc plate fasteners.

Product
LOAD WASHER

Finish
PLAIN

Black or plain finish is unfinished (bare steel). It has no actual protective coating. There may be an oil residue that provides shelf life but no corrosion protection when used. Depending on the material grade and heat treatment the colour may vary from a shiny oily appearance to a dull black finish

Size
M14

Specification / Reference
DIN 267

Length / Dimension
x28.0x3.5

Product Guides & Technical Resources


Hobson schnorr product guide

Types of washers

Schnorr high stress load washers HS material table

Product finish comparison

Washers selection guide / instructions

Washer gauge conversion chart

Product finish comparison guide
