Disc Spring - ZFS - 50x18.4x2.5 (Box=20)

Schnorr DIN EN 16983 - 50
Stock Code:
WOHTDF050025
POA

Stock Locations

  • Ballarat:
    Special Order
Make an Enquiry
Add to Favourites

Description

DESCRIPTION

Disc Spring - Zinc Flake Siver - 50 mm x18.4x2.5 (Box=20)

Managing maximum force using minimum space.

(Price per unit)

Disc springs support a lot of dynamic processes in a skillful, safe and efficient way – often under extreme force and load conditions.

Original SCHNORR® disc springs excel by:

  • An optionally linear, degressive or progressive course of the load deflection curve.
  • Long service life with dynamic load.
  • Use of high quality materials.
  • Precise adherence to force and dimension requirements.

Typical applications can include

  • Precision drilling machines.
  • Overload limitation
  • Machine tools
  • Spindles
  • Actuators
  • Control valves
  • Pipelines subject to pressure
  • Pressure relief valves

Disc springs must be selected to match a compatible material system to ensure proper strength and performance. ie stainless steel with stainless steel, zinc plate with zinc plate

(Refer to attached documentation)

Product

DISC SPRING

Finish
ZINC FLAKE SILVER >1000HRS

ZFS provides high corrosion resistance without introducing any risk of hydrogen embrittlement. Thin coating thickness allows external thread to be mated with standard internal thread (no over-tapping)

Size
34

Specification / Reference
DIN EN 16983

Length / Dimension
x12.3x1.25
