Disc Spring - MGAL - 40x20.4x2.25 (Box=20)

Schnorr DIN EN 16983 - 40
Stock Code:
WOHTDG040055
$41.52 incl GST

Stock Locations

  • Ballarat:
    Special Order
Make an Enquiry
Add to Favourites

Description

DESCRIPTION

Disc Spring - Mechanical Galvanised - 40 mm x20.4x2.25 (Box=20)

(Price per unit)

Managing maximum force using minimum space.

Disc springs support a lot of dynamic processes in a skillful, safe and efficient way – often under extreme force and load conditions.

Original SCHNORR® disc springs excel by:

  • An optionally linear, degressive or progressive course of the load deflection curve.
  • Long service life with dynamic load.
  • Use of high quality materials.
  • Precise adherence to force and dimension requirements.

Typical applications can include

  • Precision drilling machines.
  • Overload limitation
  • Machine tools
  • Spindles
  • Actuators
  • Control valves
  • Pipelines subject to pressure
  • Pressure relief valves

Disc springs must be selected to match a compatible material system to ensure proper strength and performance. ie stainless steel with stainless steel, zinc plate with zinc plate

(Refer to attached documentation)

Product

DISC SPRING

Finish

MGAL - MGAL provides better abration resistance than HDG & does not introduce any risk of
hydrogen embrittlement. MGAL products provide similar corrosion resistance to HDG.

Size
40

Specification / Reference
DIN EN 16983

Length / Dimension
x20.4x2.25


Click here for hobson schnorr product guide

Click here for schnorr disc springs standard materials table

Click here for types of washers

Click here for product finish comparison

Click here for washer gauge conversion chart

Click here for what to look for when selecting disc springs

Click here for hobson effect of spring forces

Click here for hobson disc spring materials and tolerances

Click here for schnorr DIN 2093 tolerances

Click here for schnorr references
